The Trane XE1200 have been around for a while now. The specs to be at the higher end of efficiency back when the minimum legal installation was 12-SEER. That said, and painting with a very broad brush, I would begin to question the wisdom of investing in a large repair bill on a unit that is more than 10-years of age. Consider that many manufacturers are currently allowing 10-years of internal parts warranties on their equipment and therefore, anything that fails in less than 10-years is a premature failure. This article is about Trane XE1200 Specs and Reviews.
The Trane XE 1200 is a discontinued trane air conditioner. It has three-phase heat pump with an efficiency of 12.00 SEER and 8.00 HSPF. This unit has ranged in size from 1.5 to 5 tons and featured a single-stage Climatuff compressor and spine fin aluminum coils. The cabinet was constructed of full-side louvered panels with a baked-on powder paint finish and corrosion-resistant screws.
Trane XE1200 is now 1-SEER below the minimum efficiency rating allowed for new installations. So again, I’d plan on 15+ years but would think twice or three times before investing any significant money in the system once it reaches 10-years. That’s IMO and of course, you’re free to do as you choose. Just trying to give some reasonable perspective.
Trane XE1200 Specs
Lowers Utility Bills
- 12.00 SEER Range on TTP Air Conditioner
- 12.00 SEER Range and 8.00 HSPF on TWP Heat Pump
Lasts a Long Time
- Climatuff® Compressor
- Full-Side Louvered Panels
- Baked-On Powder Paint
- Corrosion-Resistant Screws
- Torture Tested
- Spine FinTM Coils
Trane XE1200 Air Conditioner Diagram
| Model | Nominal Tons | Height (in.) | Width (in.) | Depth (in.) |
| TTP018C | 1.5 | 29 | 33 | 29 |
| TTP024C | 2 | 33 | 33 | 29 |
| TTP030D | 2.5 | 41 | 33 | 29 |
| TTP036D | 3 | 41 | 33 | 29 |
| TTP042D | 3.5 | 37 | 39 | 35 |
| TTP048D | 4 | 37 | 39 | 35 |
| TTP060E | 5 | 37 | 39 | 35 |
Trane XE1200 Heat Pumps Diagram
| Model | Nominal Tons | Height (in.) | Width (in.) | Depth (in.) |
| TWP018C | 1.5 | 24 | 28 | 25 |
| TWP024C | 2 | 29 | 33 | 29 |
| TWP030D | 2.5 | 33 | 33 | 29 |
| TWP036C | 3 | 37 | 39 | 35 |
| TWP042C | 3.5 | 37 | 39 | 35 |
| TWP048C | 4 | 37 | 39 | 35 |
| TWP060D | 5 | 37 | 39 | 35 |
Trane XE1200 Warranty
Backed by Trane’s Industry Leading Limited Warranty
- Ten-Year Limited Warranty on Compressor and Outdoor Coil if installed on or after October 1, 2001 and manufactured on or after January 1, 2000. Earlier installations have Five-Year Compressor and Coil Limited Warranty
- Five-Year Limited Warranty on Internal Functional Parts
- Five-year Internal Functional Parts Limited Warranty is effective on Units installed after October 1, 2001 and manufactured January 1, 2000 or after. Earlier installations have One-Year Warranty
- Optional Extended Warranties Available. Extended Warranties cover Labor, Refrigerant and Other Costs not covered by Manufacturers Limited Warranty
- Ask Your Dealer for Full Warranty Information at time of purchase
Potential energy savings of Trane xe1200 may vary depending on your personal lifestyle, system settings, equipment maintenance, local climate, actual construction and installation of equipment and duct system.
Trane XE1200 Consumer Review
With this Trane XE1200 air conditioner, you will enjoy top quality and high-efficiency cooling system all at a affordable price.
